40 LED Truck Tail Light Bar, Super Bright Tail Turn Signal Brake Reverse Tail Light with Iron Net Protection for 12/24v Truck Boat Snowmobile Trailer Pickup RV Camper UTV UTE Vans

SUPER BRIGHT: 40 Hi-intensity Rectangular 3-colored LED with clear transmittance PC cover , high visibility in daylight, midnight, raining or fog days. Improve the driver security and avoid accidents
Waterproof: Waterproof Rate:IP65. it can work on heavy rainy weather or in heavy snow weather
Compliant with DOT standards: The lamp shade of utility trailer light with a new PC material, The iron bracket on the backseat and the iron net in front of the lampshade, protect the whole LED light bar effectively. Build a red reflection into the red portion of the lens. Compliant with DOT standards
Easy Installation – Design with 5 WIRES connection system:Black wire: Ground wire. Red wire: brake light. Green wire: tail/running light. White wire: reverse light. Yellow wire: turn signal light.
Widely Used: come with bolts and screws and Gasket, surface mounting; Ideal for 5 wire system vehicles with DC 12-24V Power Supply, , such as truck, trailer, boat, bus, lorry, van, caravan, snowmobile, etc.
Easy to Installation

How to install ?
Black Wire: Ground
Gray Wire+Red Wire: Brake Light
Gray Wire+Green Wire: Running Light
Gray Wire+White Wire: Reverse Light
Gray Wire+Yellow Wire: Turn Signal Light
Specifications

Working Voltage: DC 12-24V
LED Light Color: Red + Amber + White
Number of LED: 40 (20 Red + 12 Amber + 8 White)
Lamp Power: 0.2*40(W)
Material: ABS Iron Housing + PC Lens
Shape: Rectangular
Waterproof Rate: IP65
Lifespan: Over 50000 Hours
Dimension: 13.5*6.10*2 Inch
