CZC AUTO 12V LED Low Profile Submersible Rectangular Trailer Light Kit Tail Stop Turn Running Lights for Boat Trailer Truck Marine

Kit includes 2 combination Submersible running/stop/tail/turn signal lights,license plate bracket and Mounting Hardware?? 25ft length of 4 pin wire Harness for enough use.UPDATE ON 9TH,JUNE,2019.FOR BETTER SERVICE ON OUR CUSTOMER,WE IMPROVED THE WIREHARNESS TO 18GAUGE 100% COPPER WIRE FOR WATERPROOF USE
Waterproof and Submersible Feature and Testing??2nd Image????We placed light underwater for 3 hour by 3 times each day ,total 5 days,the light worked great underwater! The lights are definitely waterpoof and submersible.Please make sure wires connect correctly and no electronic short before marine/underwater
Left light have 22 diodes which include 4 diodes for lincense plate light function,Right light have 18 diode. Super bright LED quality ,Complies with DOT standards
Each rectangular light size??8″ Length* 2-3/4″ width* 3″ height,Stainless steel hardware for under and over80″ marine towing vechiles
CLIENT SUPPORT: Please feel free to contact us at first if there is any problem when you receive or use our products. We are always here to support you.
Fitment Type

Fit for under and over 80ft width boats
Fit for under and over 80ft width RVs
Fit for under and over 80ft width trailers

CZC AUTO 12V LED Low Profile Submersible Trailer Light Kit

Complete Trailer Light Kit with Everything You Need

Come with tail lights wires license plate bracket screw bag instruction. Buy one get all you need.

2 combination running stop tail turn signal license plate illumination rear lights
1 23ft + 2ft split Y-style color coded harness with 4-pin male and female connectors
1 plastic license plate bracket
1 mounting hardware bag
1 assembly and operating instructions

Submersible and Waterproof

Please note: these trailer lights are sealed from PCB rather than the outer housings. The water can go into the housing and there are gaping holes on the housing for water to flow out.

All LED Tail Lights

Super High visibility and Longer Lifetime LED advantage!
100% comply with DOT standards. Left LED Light have 22 diodes: 12 diodes at front 6 diodes on side and 4
white diodes facing down for license Plate illumination.
Right Light
have 18 diodes: 12 diodes at front 6 diodes on side

Tail Light Size

Each rectangular tail lights with size 8″ Length* 2-3/4″ width* 3″ height are equiped with stainless steel hardware for under and over 80″ marine towing vechiles

Wire Connection

Connect the BROWN wire of the Trunk Harness(4)to the towing vehicle’s Running Lights wire. Connect the YELLOW wire of the Trunk Harness to the vehicle’s Left Stop Turn light. Connect the GREEN wire to the towing vehicle’s Right Stop Turn light. Attach the WHITE GROUND wire to the towing vehicle’s frame
When connect the wires please especially note the white ground connection. Please insure the lights are really connected to the ground and form a closed cycle.
